MIRO TR 90-250VAC OPTO-COUPLER MODULE
Product may differ from image

MIRO TR 90-250VAC OPTO-COUPLER MODULE

IN: 250 VAC - OUT: 48 VDC / 0,5 A
Art.No.: 52507
Alternative product:    6652507
Weight: 0.026 kg
In production
 Product Comparison
List price per piece:

You might also like

Transistor 0.5 A
230 V AC
Screw terminals
General data
Dimensions H×W×D 78×6.2×70 mm
Test isolation voltage 3.75 kV
Housing Black plastic, flame retardant
Mounting method DIN-rail mountable (EN 60715)
Temperature range -20...+60 °C
Output
Switching voltage 5...48 V DC
Switching current per output 0.1 mA...0.5 A
Leakage current (output is open) max. 0.3 mA
Saturation voltage (across output) max. 1.2 V DC
Switching time ON/OFF 55/15 ms
Switching frequency max. 500/30 Hz (resist./ind.)
Input
Voltage range ON 90...250 V AC
Voltage range OFF 0...40 V AC
Control current 7 mA
LED display LED (yellow)
Commercial data
country of origin CZ
customs tariff number 85414090
EAN 4048879026888
eClass 27371604
Packaging unit 1

Data Regarding Article:
  • Download Data Sheet
  • Download Approval: CSA CA 52507_080128-0-000_C3211-07_CSA_Z_B.PDF
  • Download Approval: CSA US 52507_080128-0-000_C3211-07_CSAU_Z_B.PDF
  • Download Approval: UL Registered CA 52507_E140415-NKCR8_URC_Z_D.PDF
  • Download Approval: UL Registered US 52507_E140415-NKCR2_UR_Z_D.PDF
  • Download Construction files: DXF 52002_DXF_X_A.ZIP
  • Download Construction files: P8 52507_P8_2_60.ZIP
  • Download Construction files: STP 52002_STP_X_A.ZIP
  • Download Information: EU declaration of conformity 52507_1528-04.16_CE_Z_C.PDF
  • Download Information: MTTF Report 52507_SN29500(40°C)-BERECHNUNG_MTTF_P_A.PDF
cURus
cCSAus
