SOLID67 DIO16 60mm M12L 5P
Product may differ from image

SOLID67 DIO16 60mm M12L 5P

SOLID67 Multiprotocol Profinet or EthernetIP
Art.No.: 54503
Weight: 0.507 kg
Available
 Product Comparison
List price per piece:
Digital inputs/outputs
DIO16
M12 Power, 5-pole, L-coded
60 mm
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
General data
Mounting method 2-hole screw mounting
Temperature range -20...+70 °C
Protection IP67
Dimensions H×W×D 30.7×60×200 mm
Output
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Switching current per output max. 2 A (short-circuit and overload protected)
Input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Type for 3-wire sensors or mechanical switches, PNP
Parameterization
PIN 4 Input/Output (port X1...X8)
PIN 2 Input/Output (port X1...X8)
Connections
Fieldbus Ethernet 10/100 Mbit/s; M12, D-coded
Sensor-system/actuator supply M12 Power, 5-pole, L-coded
I/O ports M12, 5-pole, A-coded
PROFINET
Specification V2.3, Conformance Class C (IRT)
Addressing DCP
PROFINET Netload Class III
MRP yes
EtherNet/IP
QC (Quick Connect) max. 500 ms
Addressing DHCP, BOOTP or IP address by rotary switch
DLR (Device Level Ring) yes
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Actuator warning via LED and BUS
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Cable break per port
Commercial data
country of origin DE
customs tariff number 85389099
EAN 4048879752275
eClass 27242604
Packaging unit 1.000
Data cableShow all
Power cableShow all
Sensor-actuator cableShow all

Data Regarding Article:
  • Download Data Sheet
  • Download Approval: UL Listed CA 54503_E201820-NRAQ7_ULC_Z_A.PDF
  • Download Approval: UL Listed US 54503_E201820-NRAQ_UL_Z_A.PDF
  • Download Certificate: ProfiNet  54503_Z12129-13.04.2020-V2.33_PN_Z_A.PDF
  • Download Configuration Files: GSDML 54501_SOLID67_KF0_X_11.ZIP
  • Download Construction files: DXF 54503_DXF_X_A.7Z
  • Download Construction files: P8 54503_P8_2_50.ZIP
  • Download Construction files: STP 54503_STP_D_A.7Z
  • Download Document: Installation guide 54503_INA_X_12.ZIP
  • Download Document: User manual 54500_HDB_X_12.ZIP
  • Download Information: EU declaration of conformity 54503_10-05.18_CE_Z_A.PDF
  • Download Information: MTTF Report 54503_TELCORDIA(20°C,60°C)-BERECHNUNG_MTTF_P_A.PDF
